UKF4 series SAA Australian IP66 Waterproof Mini Isolator Switch / Isolating Switch 2 Position
Product Summary
Product Details
outdoor plug socket
,weatherproof electrical outlet
Product Description
UKF4 series SAA Australian IP66 Waterproof Mini Isolator Switch / Isolating Switch 2 Position
Purple Horn IS THE REAL BUILDER “UKF”
Descriptions:
1. The waterproof isolating switch is suitable for outdoor isolation use in different weather condition including single, double and triple pole, four pole switches 10,16,20 Amps,
2. A safety feature for mounting switches to metal structures is the insulating caps that cover base mounting screws to totally protect them from any live cables.
3. Each unit is supplied with screwed conduit plugs and screwed reducers for easy connection to 25mm or 20mm conduits and screw cap. Screw caps must be installed to ensure IP Rating .
4. The impact Resistant base and cover will survive the hardest knocks in almost any installation. The two sections are sealed with a one piece weather seal gasket.
5. For security, a 7mm diameter hole is provided for padlocking the lever in the OFF position .
6. Deep molded barriers protect the operating lever from physical abuse or accidental switching.
Wiring:
1. Cables looped in and out from overhead.
2. In and out from underground
3. In and out straight through the switch.
4. Two 25mm rear knockouts are moulded in the base for surface mounting with concealed wiring.
Specifications:
| Model | UKF4 |
| Rated Current | 10A, 16A,20A |
| Rated Voltage | AC 250V |
| Type | 1 / 2 Position(OFF-ON) |
| Contact | DPST, SPST |
| Waterproof Grade | IP66 |
| Mount Hole Center Distance | 69 x 69mm/2.7" x 2.7"(L*W) |
| Fixing Mount Hole Diameter | 6mm/2.4" |
| Total Size | 85 x 85 x 80mm/3.3" x 3.3" x 3.2"(L*W*H) |
| External Material | Plastic |
| Color | Gray RAL7035 |
| Net Weight | 215g |
| Package Content | 1 x Isolator Switch |
Applications:
1: UKF4 weatherproof switch is used to isolate to ensure the safety of maintenance work.
2: It can also be used for certain circuit switching operation to change the system runs
3: UKF4 weather protected switch has superior waterproof and dustproof function, along with anti-corrosion, anti-UV, cold temperature, aging, etc
4: UKF4 Series waterproof switch has perfect protection to your safe for using of electricity in the rain, dust, freezing, high temperature, strong ultraviolet radiation and other harsh outdoor environments demand.
5: It is widely used in power, winery, sporting, outdoor, shipyards and all industries field.
Declare:
Purple Horn is the leading manufacturer for this series switch. As time going by, there are some companies that
copy our product & use our model number. Hereby, we claim that “UKF” is named by Purple Horn and Purple Horn
is the first one who use it as the code for isolating switches, “U” means “you” our valued clients, “K” is for
Purple Horn; “F” is abstracted from “weatherproof”.
If you are looking for UKF weatherproof switches, please contact us freely,
