Low Voltage DC Isolator Switch 1200V 3P Surge Protector

Low Voltage 1200V 3P 5-10KA Surge Protector Protection CE Certification

Product Description

SPD series D grade surge protective device (in short: SPD, alias: surge protector, surge arrester) is suitable for
TN-S,TN-C-S,T,IT etc. power supply system of AC 50/60Hz, s1000V~, And photovoltaic s1500VDC (pv)
ac/dc power supply system,installed on the joint of LPZ1 or LPZ2 and LPZ3, it's designed according to
EN50539-11:2013,IEC61643-1, GB18802.1, it adopts 35mm standard rail, there is a failure release
mounted on the module of surge protective device. When the SPD fails in breakdown for over-heat and over-
current, the failure release will help electric device separate from the power system and give the indication
signal, green means normal, red means abnormal, it's also could be replaced for the module when has
operating voltage.

Application

It's suitable for D grade lightning-proof, SPD, SPD5 series surge protective device according to
GB188021.1,installed on the joint of LPZ1 or LPZ2 and LPZ3, usually installed in household distribution
boards, computer equipment, information equipment, electronic equip-ment and in the socket box in front
of control equipment or near the control equipment.
Notice:When you order our goods, please write the model and quantity carefully. For example: SPD5-
10/500VDC/2 or SPD-5/385/2.8 pieces.
