| Place of Origin: | CHINA |
| Brand Name: | KRIPAL |
| Certification: | CE,IEC |
| Model Number: | SPI series |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | negotiable |
| Packaging Details: | Standard export carton packing |
| Delivery Time: | 20 days and depends on ordering quantity |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 6000 pcs per month |
| Pole: | 1P,2P,3P,4P | Frequency: | 50/60Hz |
|---|---|---|---|
| Protection Rating: | IP20 | Rated Voltage: | 1000V |
| Operating Environment: | -40℃~+85℃ | Installation: | Standard Din Rail 35mm |
| High Light: | Din Rail Mounted DC Isolator Switch,DC 40KA Isolator Switch,DC Isolator Switch Surge Protector |
||
Din Rail Mounted Surge Protector Device AC 40KA Lightning Arrester SPD Protection
SPI series B grade surge protective device ( in short: SPD, alias: surge protector, surge arrester ) is suitable for TN-S,TN-C-S TT,IT etc. power supply system of AC 50/60Hz,≤1 000V~, And photovoltaic s1500VDC(pv) ac/dc power supply system,and used at the equipotential connection, which protects the electric network not shocked by the thunder and lightning, it's designed according to EN50539-1 1:2013,IEC61643- 1,GB18802.1, it adopts 35mm standard rail, there is a failure release mounted on the module of surge protective device. When the SPD fails in breakdown for over-heat and over-current, the failure release will help electric device separate from the power system and give the indication signal, green means normal, red means abnormal.
Application
SPI-150,SPI-120, SPI-100 series surge protective devices are suitable for B grade lightning-proof, used at the equipotential connection of LPZ0A or LPZ0B and LPZ1 zone, which protects the electric network not shocked by the thunder SPI-80, SPI-60 series surge protective devices are usually installed in low voltage main distribution box connected to the incoming end of the buildings.
|
Lead Time |
Normally 20 days after received your fund, but mostly depends on your quantity |
|
Leading Port |
Ningbo or Shanghai by sea or by air. If any other loading port please kindly advise and the extra inland transportation freight will be added accordingly. |
|
Trade Term |
EXW, FOB, CIF as customer need |
|
Payment Term |
T/T 30% as deposit,and 70% before delivery. |
|
Packaging |
Neutral carton, or according to customer requirements |
|
Shipping |
By Air, by sea, by express |
Our company
Zhejiang kripal Electric Co., Ltd. was founded in 1992, and now has two production bases, Yueqing in Wenzhou and Xianju in Taizhou. The company has more than 500 employees, including over 10 senior engineers, 30 professional technicists and 30 senior executives, covering an area of more than 15000 square meters. The company has passed ISO9001 quality system certification, and serves customers with high-quality service, innovative electrical solutions and competitive prices. Therefore, the products are exported to Europe, Australia, America, Africa, Oceania, Southeast Asia, Hong Kong, Macao and Taiwan, with good brand effect in the local area, and won the title of Zhejiang export famous brand enterprise. Our mission is to strive to realize the dream of professional electrical world brand, and strive to improve our company's share in the global market. Welcome to cooperate with kripal to create a better tomorrow.
Zhejiang kripal Electric Co., Ltd. was founded in 1992, and now has two production bases, Yueqing in Wenzhou and Xianju in Taizhou. The company has more than 500 employees, including over 10 senior engineers, 30 professional technicists and 30 senior executives, covering an area of more than 15000 square meters. The company has passed ISO9001 quality system certification, and serves customers with high-quality service, innovative electrical solutions and competitive prices. Therefore, the products are exported to Europe, Australia, America, Africa, Oceania, Southeast Asia, Hong Kong, Macao and Taiwan, with good brand effect in the local area, and won the title of Zhejiang export famous brand enterprise. Our mission is to strive to realize the dream of professional electrical world brand, and strive to improve our company's share in the global market. Welcome to cooperate with kripal to create a better tomorrow.
