| Place of Origin: | CHINA |
| Brand Name: | KRIPAL |
| Certification: | CE,IEC |
| Model Number: | SPI series |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | negotiable |
| Packaging Details: | Standard export carton packing |
| Delivery Time: | 20 days and depends on ordering quantity |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 6000 pcs per month |
| Pole: | 1P,2P,3P,4P | Rated Voltage: | 1000V |
|---|---|---|---|
| Frequency: | 50/60Hz | Operating Environment: | -40℃~+85℃ |
| Installation: | Standard Din Rail 35mm | Protection Rating: | IP20 |
| High Light: | DC Surge Protective Device Isolator Switch,PV DC 1000V Isolator Switch,60Hz DC Isolator Switch |
||
CE Certification PV DC Surge Protective Device 1000V 40kA For Outdoor Protection
SPI series B grade surge protective device ( in short: SPD, alias: surge protector, surge arrester ) is suitable for TN-S,TN-C-S TT,IT etc. power supply system of AC 50/60Hz,≤1 000V~, And photovoltaic s1500VDC(pv) ac/dc power supply system,and used at the equipotential connection, which protects the electric network not shocked by the thunder and lightning, it's designed according to EN50539-1 1:2013,IEC61643- 1,GB18802.1, it adopts 35mm standard rail, there is a failure release mounted on the module of surge protective device. When the SPD fails in breakdown for over-heat and over-current, the failure release will help electric device separate from the power system and give the indication signal, green means normal, red means abnormal. Kevin wiring mode,remote-signaling output interface. SPI2 and SPI4 Series surge protection module can be replaced online.
Application
SPI-150,SPI-120, SPI-100 series surge protective devices are suitable for B grade lightning-proof, used at the equipotential connection of LPZ0A or LPZ0B and LPZ1 zone, which protects the electric network not shocked by the thunder SPI-80, SPI-60 series surge protective devices are usually installed in low voltage main distribution box connected to the incoming end of the buildings.
|
Lead Time |
Normally 20 days after received your fund, but mostly depends on your quantity |
|
Leading Port |
Ningbo or Shanghai by sea or by air. If any other loading port please kindly advise and the extra inland transportation freight will be added accordingly. |
|
Trade Term |
EXW, FOB, CIF as customer need |
|
Payment Term |
T/T 30% as deposit,and 70% before delivery. |
|
Packaging |
Neutral carton, or according to customer requirements |
|
Shipping |
By Air, by sea, by express |
