IP67 63A 4 Pole Waterproof Industrial Connector Nickel Plated

IP67 63A 4 Pole Waterproof Industrial Connector Nickel Plated

  • IP67 63A 4 Pole Waterproof Industrial Connector Nickel Plated
  • IP67 63A 4 Pole Waterproof Industrial Connector Nickel Plated
IP67 63A 4 Pole Waterproof Industrial Connector Nickel Plated
Product Details:
Place of Origin: CHINA
Brand Name: KRIPAL
Certification: CE
Model Number: UKS-C346-6
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: negotiable
Packaging Details: Each unit packed in a individual box
Delivery Time: 30 days and depends on ordering quantity
Payment Terms: T/T, L/C, D/P
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Rated Current: 63A Pole: 3P,4P,5P
Rated Voltage: 110V,220V,380V,500V IP Code: IP67
Material: Nylon,PA,PC,copper Advantage: Waterproof,dustproof,safety
High Light:

Nickel Plated 220V Industrial Socket


Dustproof 220V Industrial Socket


Ip67 Industrial Power Plug

IP67 63A 4 Pole Waterproof Industrial Connector Nickel Plated




Current Position Voltage Color Poles Model
63A 4h 110-130V Yellow 2P+E UKS-C336-4
6h 220-250V Blue 2P+E UKS-C336-6
9h 380-415V Red 2P+E UKS-C336-9
4h 110-130V Yellow 3P+E UKS-C346-4
9h 220-250V Blue 3P+E UKS-C346-9
6h 380-415V Red 3P+E UKS-C346-6
4h 110-130V Yellow 3P+N+E UKS-C356-4
9h 220-250V Blue 3P+N+E UKS-C356-9
6h 380-415V Red 3P+N+E UKS-C356-6


IP67 63A 4 Pole Waterproof Industrial Connector Nickel Plated 0





Prouduct Feature


1. High security and reliability


a. Different types of plugs and sockets prevent mis-insertion due to different plug clock positions, diameters and pole numbers, which is safe and reliable.


b. The ground pole socket in the socket is longer than the phase pole socket, which ensures that the ground pole is first connected when plugging, and the ground pole is finally separated when it is pulled out, which is very safe.


c. The elastic sleeve is added to the insert sleeve to ensure good contact with the plug after the connection, so as to avoid burning the plug socket due to poor contact heat; high protection level. Can be used under poor environmental conditions.


d. The anti-drop device is installed to greatly improve the safety and reliability of the plug and socket power connection.



2. It is made of high quality engineering plastic nylon (PA66).


High temperature resistance, good insulation performance; resistant to impact, not afraid of falling and stepping on, overcoming the shortcomings of the old plug and socket falling and fragile.



3. Easy to use


The new generation of industrial plugs and sockets are widely used because of their versatility, high safety and reliability, quick installation, convenient connection and insertion, simple operation, and wide variety of specifications, suitable for user selection and international integration.





Product Application

Applied to Power distribution equipment.
Applied to power systerm.
Applied to Construction site.
Applied to Port and pier.
Applied to Machinery industry.
Applied to Large modern buildings.
Applied to Large public space.
Applied to Transportation equipment.




Product Test

As is well-know , the prodcut in working condition or in storage condition , tends to be afected by various kinds of liquid more or less.
The osmosis , fow , impact or accumulation of liquid may have a variety of efect on the product material and performance , and even may destory its structure.
Therefore m the afect from liquid can not be ignored.
The purpose of rainfall test is to confirm the reverse osmose capacity of the housing and its operation stability and reliability when or after the equipment undergoes liquid erosion.


We produce products avaliable for use around the world , so one of problems taken into account is the operational environment for the product , so as to evaluate the prodcut adaptability
of stroage , transport or operation when it's exposed to atmosphere with dry sand or dust .
Sand and dust tast adopts simulated sand and dust environment to test the dust resistance of the product and to confirm whether the product can be used for long in various hostile natural environment .



At product design , first we define a logical temperature rise range , and then we do best to make the product with a best insertion and extraction handle within the range.
The purpose of insertion and extraction test is to convert emotional handle into rational data for the use in product design , improvement , evaluation and delivery inspection


We design and develop products , taking into account performance indexes of parts like metal conductive parts, and the CTI/PTI of plastic materials as wells.
The material selection for each development must undergo strictly controlled CTI/CPI for the purpose of better insulating property and safe operation 400v industrial plug and socket.

IP67 63A 4 Pole Waterproof Industrial Connector Nickel Plated 1




IP67 63A 4 Pole Waterproof Industrial Connector Nickel Plated 2




Q: What is your terms of payment?

A: T/T 30% as deposit,and 70% before delivery.We'll show you the photos of the products and packages before you pay the balance.


Q: What is your terms of delivery?



Q: Can you produce according to the samples?

A: Yes,we can produce by your samples or technical drawings. We can build the molds and fixtures.


Q: Do you offer OEM service?

A: Yes,we have been providing OEM/ODM service to global manufacturers and suppliers for many years.


Q: What’s the standard of package?

A: Export standard package or special package according to customer.




Our Company


Zhejiang kripal Electric Co., Ltd. is a national high-tech enterprise specializing in R & D, production and sales. Our products mainly include: small, molded case circuit breakers, AC contactors, building electrical, outdoor waterproof, control components, industrial plugs and sockets, etc.


The company was founded in 1992, after 30 years of vigorous development, the existing plant area of more than 15000 square meters, more than 500 employees, including over 10 senior engineers, 30 professional technicists and 30 senior executives. The products have passed the certificate of UL,VDE,TUV, Kema,Semko,SAA,CE and CB test report,also ROHS international certification, and obtained the national 3C, ISO9001 quality certification.


The company adheres to the enterprise policy of "management, independent innovation, coordination and cooperation, brand supremacy" and abides by the promise of "virtue in the world". Practice the core values of "win-win cooperation with customers, common prosperity with employees, benefit creation for the company and harmonious contribution to society", and strive for the mission of "strive to realize the dream of professional electrical world brand".


We sincerely welcome new and old customers at home and abroad to contact us and create a better future.
