| Place of Origin: | China |
| Brand Name: | KRIPAL |
| Certification: | SAA,SEMKO,CE CERTIFICATE,CB TEST REPORT |
| Model Number: | UKF2-435 |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | negotiable |
| Packaging Details: | Each unit packed in a individual box |
| Delivery Time: | 20 days and depends on ordering quantity |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 100000 pcs per month |
| Rated Current: | 35A | Material: | PC、Copper |
|---|---|---|---|
| Protection Degree: | IP66 | Pole: | 4P |
| Frequency: | 50/60Hz | Advantage: | Dustproof,Anti-corrosion,Anti-ultraviolet |
| Brand Name | KRIPAL |
| Model Number | UKF2 |
| Type | Weatherproof Isolator switch |
| Number of poles | 1P,2P,3P,4P |
| Current | 10A,16A,20A,35A,63A |
| Frequency | 50/60Hz |
| Protection | IP66 |
| Material | PC,Copper |
| Standard | IEC/EN60947,AS/NZS 3123:2005 |
| Identification | SAA,SEMKO,CE CERTIFICATE,CB TEST REPORT |
| Color | Gray&White |
| Warranty | One and a half years |
| Current(A) | Rated Voltage(V) | Pole(P) | Type |
| 20 | 250 | 1 | UKF2-120 |
| 440 | 2 | UKF2-220 | |
| 3 | UKF2-320 | ||
| 4 | UKF2-420 | ||
| 35 | 250 | 1 | UKF2-135 |
| 440 | 2 | UKF2-235 | |
| 3 | UKF2-335 | ||
| 4 | UKF2-435 | ||
| 63 | 250 | 1 | UKF2-163 |
| 440 | 2 | UKF2-263 | |
| 3 | UKF2-363 | ||
| 4 | UKF2-463 |
1. The base mounting device provides easier terminating and greater wiring space.
2. Install the ground and neutral connection rod. Use double fastening screws to effectively fix all cables on the junction box and reliably clamp them to prevent liquid leakage
3. Higher safety, the installation switch to the metal structure is provided with an insulation cap, the insulation cap covers the base mounting screw, to prevent it from contacting the live cable.
4, each device is provided with threaded conduit connector and threaded reducing pipe, used to connect 25mm or 20mm conduit and nut; Nuts must be installed to ensure IP rating.
5. Impact-resistant base and cover plate can withstand severe impact under almost all installation conditions. The base and cover plate are separated by weather-resistant waterproof sealing ring.
6. For safety, provide a 7mm diameter hole for locking the lever in the OFF position. A depth - mounted partition ensures that the lever prevents accidental operation.
7, all products are in line with IEC60947-3 standard, the standard color of the switch is gray.
Products are widely used in smelting, chemicals, power electronics, airports, railways, construction sites, mines, quarries, water supply and drainage treatment plants, automobile manufacturing, ports, docks, shopping malls, hotels and other places.
| Lead Time | Normally 20 days after received your fund, but mostly depends on your quantity |
| Leading Port | Ningbo or Shanghai by sea or by air. If any other loading port please kindly advise and the extra inland transportation freight will be added accordingly. |
| Trade Term | EXW, FOB, CIF as customer need |
| Payment Term | T/T 30% as deposit,and 70% before delivery. |
| Packaging | Neutral carton, or according to customer requirements |
| Shipping | By Air, by sea, by express |
1.Reply inquiry in 24 hours;
2. Strong production capacity and strict quality control system;
3. Your inquiry and problems related to our products or prices will be replied in 24 hours;
4. Well-trained and experienced staffs to answer all your inquires;
5. OEM & ODM are available; there is an our own mould tooling center in KRIPAL factory.
Zhejiang kripal Electric Co., Ltd. was founded in 1992, and now has two production bases, Yueqing in Wenzhou and Xianju in Taizhou. The company has more than 500 employees, including over 10 senior engineers, 30 professional technicists and 30 senior executives, covering an area of more than 15000 square meters. The company has passed ISO9001 quality system certification, and serves customers with high-quality service, innovative electrical solutions and competitive prices. Therefore, the products are exported to Europe, Australia, America, Africa, Oceania, Southeast Asia, Hong Kong, Macao and Taiwan, with good brand effect in the local area, and won the title of Zhejiang export famous brand enterprise. Our mission is to strive to realize the dream of professional electrical world brand, and strive to improve our company's share in the global market. Welcome to cooperate with kripal to create a better tomorrow.
