Waterproof Ammeter Changeover Switch Rotary Cam Switch 63A 4P IP65

Waterproof Ammeter Changeover Switch Rotary Cam Switch 63A 4P IP65

  • Waterproof Ammeter Changeover Switch Rotary Cam Switch 63A 4P IP65
  • Waterproof Ammeter Changeover Switch Rotary Cam Switch 63A 4P IP65
Waterproof Ammeter Changeover Switch Rotary Cam Switch 63A 4P IP65
Product Details:
Place of Origin: China
Brand Name: KRIPAL
Certification: VDE,SEMKO,CE CERTIFICATE,CB TEST REPORT
Model Number: UKPN5-480
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: negotiable
Packaging Details: Each unit packed in a individual box
Delivery Time: 20 days and depends on ordering quantity
Payment Terms: T/T, L/C, D/P
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Protection Degree: IP65 Rated Current: 63A
Voltage: 230-440V Pole: 3P,4P
Frequency: 50/60Hz Material: PC、Copper
High Light:

Load Break Rotary Changeover Switch

,

150A Rotary Changeover Switch

,

IP65 Electrical Changeover Switch

Ammeter Changeover Switch Rotary Cam Switch 63A 4P IP65







Product Description



This is a rotary load isolating switch used for line connection, disconnection and line maintenance or load maintenance for isolation. It includes a movable contact support part, a transmission mechanism, a static contact, and a shell,Wiring seat, base.Because it adopts a spiral transmission mechanism to realize the structure of closing and breaking of moving and static contacts, and at the same time adopts a scroll spring as an energy storage spring, it can ensure fast closing and breaking speeds. The product has good stability and high on-off capability. In addition, the product not only allows the operator to clearly see the opening and closing conditions of the moving and static contacts, but also prohibits the misoperation of the closing of unrelated personnel. It has the advantages of reasonable, ingenious design, safe and reliable, convenient and practical, and excellent performance.



 Rated current  10A,16A,20A,25A,32A,40A,50A,63A,80A,100A,125A,150A
 No. of poles  3P,4P
 Voltage  230-440V
 Protection degree  IP65
 Frequency  50/60Hz
 Standard  IEC/EN60947
 Material  PC, Copper
 Warranty  One and a half years

Waterproof Ammeter Changeover Switch Rotary Cam Switch 63A 4P IP65 0





Reference Model



Current(A) Rated Voltage(V) Model
3P 4P
10 230-440V UKPN0-310 UKPN0-410
16 230-440V UKPN0-316 UKPN0-416
20 230-440V UKPN0-320 UKPN0-420
20 230-440V UKPN1-320 UKPN1-420
25 230-440V UKPN1-325 UKPN1-425
32 230-440V UKPN1-332 UKPN1-432
32 230-440V UKPN3-332 UKPN3-432
40 230-440V UKPN3-340 UKPN3-440
50 230-440V UKPN3-350 UKPN3-450
63 230-440V UKPN3-363 UKPN3-463
63 230-440V UKPN5-363 UKPN5-463
80 230-440V UKPN5-380 UKPN5-480
100 230-440V UKPN5-3100 UKPN5-4100
125 230-440V UKPN5-3125 UKPN5-4125
150 230-440V UKPN5-3150 UKPN5-4150



Maintenance switch

Load isolation switch UKP can be used as a maintenance switch or a main switch with a shell to connect various electrical loads. The open position can be equipped with multiple padlocks. To ensure personal safety, the open position should be clear, not automatically reset. Safety switches comply with IEC 60947-3 standard and GB14048.3





Proper installation ways

①Surface installation(insulation enclosure assembled)

②Parallel and level installation(fix in front of it)

③Rear installation(fix at the back of it,door linkage or cover linkage)









Product Feature





1.The full range: According to the classification power capacity, can provide the most economical solution for different projects; nameplate There are many different methods of installation, flexibility to meet the needs of specific applications.



2.Flexible application:800 standard contact combinations are available,with an almost unlimited number of switch combinations.



3.Safe and reliable: The terminal with protective cover conforms to VDE0106 to ensure the safety of finger touch.



4.It can be reliably used in lighting equipment, heating equipment and motors, and can directly switch the motor (AC-3). Its high on-off capability ensures the reliability of the work during frequent on-off.



5.It has a variety of uses in industrial machinery and equipment.For example,when used as maintenance switch and insurance switch,3 padlocks can be installed in O part to ensure the personal safety of users.



6.Beautiful appearance,novel,simple,small size and function are the ideal choice among similar products.







Application



Main switch are ON--OFF switches to isolated the power to a particular area of operation.According to ICE/EN6024 or VDE0113,all electrical equipments of industrial machines must be equipped with a main switch.This must permit disconnection of all the elecrical equipment during cleaning,maintenance and repair work,and other extended periods when is stationary.Main switch can be used for switching and controlling main circuits,motor ON-OFF and other special application circuits,such as illumination equipments,heating equipments and motors,Their high on-off ability ensure the work reliability of frequently making and breaking.









Packaging & Delivery


 Lead Time  Normally 20 days after received your fund, but mostly depends on   your quantity
 Leading Port  Ningbo or Shanghai by sea or by air. If any other loading port please   kindly advise and the extra inland transportation freight will be added   accordingly.
 Trade Term  EXW, FOB, CIF as customer need
 Payment Term  T/T 30% as deposit,and 70% before delivery.
 Packaging  Neutral carton, or according to customer requirements
 Shipping

 By Air, by sea, by express









FAQ



Q:Are you factory?

A:Yes ,our factory is located in Wenzhou, one hour to Yiwu and two hours to Hangzhou by train, and one hour to Shanghai by air .Also very near to Wenzhou international Airport and Yueqing train station.



Q:Do you offer OEM service?

A:Yes,we have been providing OEM/ODM service to global manufacturers and suppliers for many years.



Q:How many employees do you have?

A:We have more than 500 employees now,with in-house R&D teem.



Q: What is your sample policy?

A: Sample is available ,but sample should be paied in advance. The cost of sample will be refund after further order.



Q: Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery
