IEC Standard 50A 3P IP65 Electric Waterproof Isolator Switch 230-440V

IEC Standard 50A 3P IP65 Electric Waterproof Isolator Switch 230-440V

  • IEC Standard 50A 3P IP65 Electric Waterproof Isolator Switch 230-440V
  • IEC Standard 50A 3P IP65 Electric Waterproof Isolator Switch 230-440V
  • IEC Standard 50A 3P IP65 Electric Waterproof Isolator Switch 230-440V
IEC Standard 50A 3P IP65 Electric Waterproof Isolator Switch 230-440V
Product Details:
Place of Origin: China
Brand Name: KRIPAL
Certification: VDE,SEMKO,CE CERTIFICATE,CB TEST REPORT
Model Number: UKP3-350
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: negotiable
Packaging Details: Each unit packed in a individual box
Delivery Time: 20 days and depends on ordering quantity
Payment Terms: T/T, L/C, D/P
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Rated Current: 50A Material: PC、Copper
Pole: 3P Frequency: 50/60Hz
Application: Control Motor Advantage: Prevent The Loss Caused By Long-term Illumination,safety,low-energy
High Light:

Electric Waterproof Isolator Switch

,

IEC Standard Waterproof Isolator Switch

,

440V Rotary Isolator Switch

IEC standard 50A 3P IP65 Electric Waterproof Isolator Switch





Product Description



1.Rated insulation voltage 230V-440V, current 10A~150A,commonly used in single-phase or three-phase AC system;

2.IP65 box body design, with the import of the sealing strip of the safety seal and dust,waterproof, anti ultraviolet materials;

3.Switch rotating operator (knob) with three lock position, reliable to prevent misuse;

4.Suitable for different cable connectors: M25, M20, M16 and M12, optional waterproof cable connectors;

5.Large wiring operation space, the product is fixed on the box body, the connection is still convenient;

6.Adequate internal space, good heat dissipation effect;

7.Large contrast color design, easy to distinguish;

8.Protection degree: IP65.







IEC Standard 50A 3P IP65 Electric Waterproof Isolator Switch 230-440V 0

IEC Standard 50A 3P IP65 Electric Waterproof Isolator Switch 230-440V 1







Reference Model



IEC Standard 50A 3P IP65 Electric Waterproof Isolator Switch 230-440V 2







Proper installation ways



① Rear installation(fix at the back of it,door linkage or cover linkage)

② Surface installation(insulation enclosure assembled)

③ Parallel and level installation(fix in front of it)




Product Feature



1.Safe and Reliable: the terminals equipped with protective cover conform to VDE0106,to ensure the safety of finger touch

2.It has a variety of uses in industrial machinery and equipment.For example,when used as maintenance switch and insurance switch,3 padlocks can be installed in O part to ensure the personal safety of users.

3.It can be used reliably in lighting equipment,heating equipment and motors reliably,in addition,they also can switch the motor(AC-3) derectly,its high on-off ability can ensure the work reliability at frequently making and breaking.

4.Complete variety:according to the power capacity classification,can provide the most economical solution for different projects;there are a variety of different installation methods of the nameplate,can be flexible to meet the needs of specific applications.

5.Beautiful appearance,novel,simple,small size and function are the ideal choice among similar products.
