| Place of Origin: | China |
| Brand Name: | KRIPAL |
| Certification: | VDE,SEMKO,CE CERTIFICATE,CB TEST REPORT |
| Model Number: | UKF3-320 |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | negotiable |
| Packaging Details: | Each unit packed in a individual box |
| Delivery Time: | 20 days and depends on ordering quantity |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 100000 pcs per month |
| Pole: | 3P | Rated Current: | 20A |
|---|---|---|---|
| Frequency: | 50/60Hz | Material: | PC、Copper、 |
| Protection Degree: | IP66 | Standard: | IEC/EN60947，AS/NZS 3123:2005 |
| Brand Name | KRIPAL |
| Model Number | UKF3 |
| Type | Weatherproof Isolating Switch |
| Number of poles | 1P,2P,3P,4P |
| Current | 20A,35A,63A |
| Frequency | 50/60Hz |
| Protection | IP66 |
| Material | PC,Copper |
| Standard | IEC/EN60947,AS/NZS 3123:2005 |
| Identification | SAA,SEMKO,CE CERTIFICATE,CB TEST REPORT |
| Color | Gray&White |
| Warranty | One and a half years |
1. UKF series weatherproof isolation switch wide range of applications, suitable for any outdoor application conditions. Including unipolar, bipolar and three-pole switch, current range 20A-63A. Base mounting arrangement provides easier termination and more wiring space. (Switch size is 165 * 82mm, total height 85mm)
2. Install ground and neutral connecting rod with double intensify screw, dial the same cable length and reliable clamping aperture terminal 5-6mm. More secure, installation switches to a metal structure with an insulating cap, insulating cap covering the base mounting screws to prevent their exposure to energized cables.
3. Each device provides a threaded pipe threaded Reducing joint connector box to connect with 25mm or 20mm conduits and screw caps. Screw caps must be installed to ensure IP Rating. For security, a 7mm diameter hole is provided for padlocking the lever in the OFF position. Deep moulded barriers protect the operating lever from physical abuse or accidental switching.
4. All units comply to IEC60947-3. Standard colours are grey & white.
Products are widely used in smelting, chemical industry, power electronics, airports, railways, construction sites, mines, quarries, water supply and drainage treatment plants, automobile manufacturing, ports, docks, shopping malls, hotels and other places. When used as maintenance switch and safety switch, the position of "on" and "off" shall be clearly marked, and the padlock hole shall be provided, and the padlock can be installed at the "off" position; If you want to lock in the "open" position, you only need to lock one hole; To ensure the safety of users.
| Lead Time | Normally 20 days after received your fund, but mostly depends on your quantity |
| Leading Port | Ningbo or Shanghai by sea or by air. If any other loading port please kindly advise and the extra inland transportation freight will be added accordingly. |
| Trade Term | EXW, FOB, CIF as customer need |
| Payment Term | T/T 30% as deposit,and 70% before delivery. |
| Packaging | Neutral carton, or according to customer requirements |
| Shipping | By Air, by sea, by express |
1. Please kindly inform us which items you are interested&the reasonable price will be provided you upon receipt of your new inquiry ASAP;
2. Your inquiry and problems related to our products or prices will be replied in 24 hours;
3. Solved the problem with you during using our products;
4. Strong production capacity and strict quality control system;
5. OEM & ODM are available; there is an our own mould tooling center in KRIPAL factory.
Zhejiang Kripal Electric Co., Ltd founded in 1992 is specialized in circuit breaker ,AC contactor , industrial plug and socket, weather protected switchgear, and others. With the repaid development in last 29years. KRIPAL act as one of the biggest manfactures in eleectrical industry in China.
With a wide marketing network ,the products are exported to Europe ,Amercia, Afric , South Asia,Hongkong , Macaw,Taiwan and othe areas and enjoy high reputation in the international market .
