| Place of Origin: | CHINA |
| Brand Name: | KRIPAL |
| Certification: | CE |
| Model Number: | UKS-I336-4 |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | negotiable |
| Packaging Details: | Each unit packed in a individual box |
| Delivery Time: | 20 days and depends on ordering quantity |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 50000 pcs per month |
| Rated Current: | 16A,32A,63A | Pole: | 3P,4P,5P |
|---|---|---|---|
| Rated Voltage: | 110V,22V,380V, | Earth Pin Direction: | 4H,6H,7H,9H |
| Material: | Nylon,PA,PC,copper | Standard: | IEC/EN 60309-2 |
| High Light: | 63A IEC Socket with Switch,IP67 IEC Socket with Switch,Mechanical Interlock Switch Socket |
||
63A 3P IP67 Socket With Switches And Mechanical Interlock IEC standard
|
Current |
Position |
Voltage |
Color |
Poles |
Model |
|
16A |
6h |
220-250V |
Blue |
2P+E |
UKS-I136-6 |
|
6h |
380-415V |
Red |
3P+E |
UKS-I146-6 |
|
|
6h |
380-415V |
Red |
3P+N+E |
UKS-I156-6 |
|
|
32A |
6h |
220-250V |
Blue |
2P+E |
UKS-I236-6 |
|
6h |
380-415V |
Red |
3P+E |
UKS-I246-6 |
|
|
6h |
380-415V |
Red |
3P+N+E |
UKS-I256-6 |
|
|
63A |
6h |
220-250V |
Blue |
2P+E |
UKS-I336-6 |
|
6h |
380-415V |
Red |
3P+E |
UKS-I346-6 |
|
|
6h |
380-415V |
Red |
3P+N+E |
UKS-I356-6 |
1. PC plugs, sockets and connectors are designed for extreme operating conditions.
They have the characteristics of easy installation, long life and high reliability. They are widely used in machinery industry, crane industry, construction industry, trains, automobiles, etc.
2. The shell and entrance are made of high-grade plastic nylon.
The material has excellent insulation ability, is unbreakable, wear-resistant and durable, and has the characteristics of oil resistance, gasoline resistance, salt water resistance, almost no aging, extreme cold resistance, and splash water resistance.
3. All units are not only suitable for the same system, but also fully compatible with the same system units of other manufacturers, through grooves and tongues, connectors of the same polarity, and easy installation through movable cable clamps, safe and reliable to use.
| Protection | IP44/IP67 |
| Current | 16A, 32A, 63A, 125A, 250A, 420A |
| Pins | 2P+E, 3P+E, 3P+N+E |
| Voltage | 20-25V; 40-50V; 110V-130V; 220-250V; 380-415V; 247V-690V |
| Plug & Socket | Low voltage plug socket <50V |
| Industrial plug, industrial socket | |
| Wall mounted socket, wall mounted plug | |
| Panel mounted socket, panel mounted plug | |
| Interlocked switched socket | |
| Box | Industrial portable socket box |
| Industrial plastic socket box | |
| Power maintenance box (stainless) | |
| Power maintenance box (plastic) | |
| Industrial lighting box (plastic) | |
| Industrial lighting box (metal) | |
| Distribution box for exhibition box | |
| T. V / Film power distribution box | |
| Distribution box with power and compress air outlet | |
| Accessories | Cap for 16A, 32A, 63A, 125A plug |
| Lead Time | Normally 20 days after received your fund, but mostly depends on your quantity |
| Leading Port | Ningbo or Shanghai by sea or by air. If any other loading port please kindly advise and the extra inland transportation freight will be added accordingly. |
| Trade Term | EXW, FOB, CIF as customer need |
| Payment Term | T/T 30% as deposit,and 70% before delivery. |
| Packaging | Neutral carton, or according to customer requirements |
| Shipping | By Air, by sea, by express |
