| Place of Origin: | CHINA |
| Brand Name: | KRIPAL |
| Certification: | CE |
| Model Number: | UKS-I154-7 |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | negotiable |
| Packaging Details: | Each unit packed in a individual box |
| Delivery Time: | 25 days and depends on ordering quantity |
| Payment Terms: | T/T, L/C, D/P |
| Supply Ability: | 50000 pcs per month |
| Frequency: | 50/60Hz | Rated Current: | 16A,32A |
|---|---|---|---|
| No Of Poles: | 3P,4P,5P | IP Code: | IP44 |
| Material: | Nylon,PA,PC,Copper | Advantage: | Dustproof,Moisture-proof,Corrosion-proof |
| High Light: | Three Phase Interlock Switched Socket,IP44 Industrial 32A Switched Socket,Mechanical Interlock Switched Socket |
||
| Current | Position | Voltage | Color | Poles | Model |
| 16A | 4h | 110-130V | Yellow | 2P+E | UKS-J134-4 |
| 6h | 220-250V | Blue | 2P+E | UKS-J134-6 | |
| 9h | 220-250V | Blue | 3P+E | UKS-J144-9 | |
| 6h | 380-415V | Red | 3P+E | UKS-J144-6 | |
| 6h | 380-415V | Red | 3P+N+E | UKS-J154-6 | |
| 7h | 500V | Black | 3P+N+E | UKS-J154-7 | |
| 32A | 4h | 110-130V | Yellow | 2P+E | UKS-J234-4 |
| 6h | 220-250V | Blue | 2P+E | UKS-J234-6 | |
| 9h | 220-250V | Blue | 3P+E | UKS-J244-9 | |
| 6h | 380-415V | Red | 3P+E | UKS-J244-6 | |
| 6h | 380-415V | Red | 3P+N+E | UKS-J254-6 | |
| 7h | 500V | Black | 3P+N+E | UKS-J254-7 |
| Product | Interlocked Switch Socket |
| Rated current | 16A,32A |
| No. of poles | 2P+E,3P+E,3P+N+E |
| Voltage | 110V;220V-250V; 380V-415V;500V |
| Protection degree | IP44 |
| Power type | Single Phase, Three Phase |
| Conductor cross-sectional area (mm2) | 1.5-4(16A), 2.5-10(32A) |
| Material | Nylon,PA, PC,Copper |
| Color | 110V(yellow) 220V,230V(blue) 380V,415V,440V(red) 500V(black) |
Safety,Environmental,Economic,Multi-function,Durable,Timesaving
Standard plug,Standard socket.
Provide different series products for different environment.
Resistance to severs weather and ageing.
Good space stability and accuracy.
Effectively prevent power outages and leakage.
Applied to Power distribution equipment.
Applied to power systerm.
Applied to Construction site.
Applied to Port and pier.
Applied to Machinery industry.
Applied to Large modern buildings.
Applied to Large public space.
Applied to Transportation equipment.
1. WATERPROOF TEST: IP DEGREE,WEATHERPROOF
As is well-know , the prodcut in working condition or in storage condition , tends to be afected by various kinds of liquid more or less.
The osmosis , fow , impact or accumulation of liquid may have a variety of efect on the product material and performance , and even may destory its structure.
Therefore m the afect from liquid can not be ignored.
The purpose of rainfall test is to confirm the reverse osmose capacity of the housing and its operation stability and reliability when or after the equipment undergoes liquid erosion.
2.SAND AND DUST TEST
We produce products avaliable for use around the world , so one of problems taken into account is the operational environment for the product , so as to evaluate the prodcut adaptability
of stroage , transport or operation when it's exposed to atmosphere with dry sand or dust .
Sand and dust tast adopts simulated sand and dust environment to test the dust resistance of the product and to confirm whether the product can be used for long in various hostile natural environment .
3. CTI/PTI TEST
We design and develop products , taking into account performance indexes of parts like metal conductive parts, and the CTI/PTI of plastic materials as wells.
The material selection for each development must undergo strictly controlled CTI/CPI for the purpose of better insulating property and safe operation.
Q: What is your terms of payment?
A: T/T 30% as deposit,and 70% before delivery.We'll show you the photos of the products and packages before you pay the balance.
Q: How about your delivery time?
A: Generally,it will take 25 days after receiving your advance payment.The specific delivery time depends on the items and the quantity of your order.
Q: What is your sample policy?
A: Sample is available ,but sample should be paied in advance. The cost of sample will be refund after further order.
Q: Do you offer OEM service?
A: Yes,we have been providing OEM/ODM service to global manufacturers and suppliers for many years.
Q: How to ship my order ? Is it safe?
A: DHL,FedEx,UPS,TNT,EMS,by sea or air,any your required.
Zhejiang kripal Electric Co., Ltd. is a national high-tech enterprise specializing in R & D, production and sales. Our products mainly include: small, molded case circuit breakers, AC contactors, building electrical, outdoor waterproof, control components, industrial plugs and sockets, etc.
The company was founded in 1992, after 30 years of vigorous development, the existing plant area of more than 15000 square meters, more than 500 employees, including over 10 senior engineers, 30 professional technicists and 30 senior executives. The products have passed the certificate of UL,VDE,TUV, Kema,Semko,SAA,CE and CB test report,also ROHS international certification, and obtained the national 3C, ISO9001 quality certification.
The company adheres to the enterprise policy of "management, independent innovation, coordination and cooperation, brand supremacy" and abides by the promise of "virtue in the world". Practice the core values of "win-win cooperation with customers, common prosperity with employees, benefit creation for the company and harmonious contribution to society", and strive for the mission of "strive to realize the dream of professional electrical world brand".
We sincerely welcome new and old customers at home and abroad to contact us and create a better future.
