Place of Origin: | CHINA |
Brand Name: | KRIPAL |
Certification: | CE |
Model Number: | UKS-C246-6 |
Minimum Order Quantity: | 1000 pcs |
---|---|
Price: | negotiable |
Packaging Details: | Each unit packed in a individual box |
Delivery Time: | 20 days and depends on ordering quantity |
Payment Terms: | T/T, L/C, D/P, MoneyGram |
Supply Ability: | 50000 pcs per month |
Rated Current: | 16A,32A | IP Code: | IP67 |
---|---|---|---|
Frequency: | 50/60Hz | Pole: | 3P,4P,5P |
Material: | Nylon,PA,PC,Copper | Standard: | IEC/EN60309-2,DIN VDE 0623 |
High Light: | IP67 Connector With Lock,380V IP67 Connector,32a Industrial Plug Socket |
Current | Position | Voltage | Color | Poles | Model |
16A | 4h | 110-130V | Yellow | 2P+E | UKS2-C136-4 |
6h | 220-250V | Blue | 2P+E | UKS2-C136-6 | |
9h | 380-415V | Red | 2P+E | UKS2-C136-9 | |
4h | 110-130V | Yellow | 3P+E | UKS2-C146-4 | |
9h | 220-250V | Blue | 3P+E | UKS2-C146-9 | |
6h | 380-415V | Red | 3P+E | UKS2-C146-6 | |
4h | 110-130V | Yellow | 3P+N+E | UKS2-C156-4 | |
9h | 220-250V | Blue | 3P+N+E | UKS2-C156-9 | |
6h | 380-415V | Red | 3P+N+E | UKS2-C156-6 | |
32A | 4h | 110-130V | Yellow | 2P+E | UKS2-C236-4 |
6h | 220-250V | Blue | 2P+E | UKS2-C236-6 | |
9h | 380-415V | Red | 2P+E | UKS2-C236-9 | |
4h | 110-130V | Yellow | 3P+E | UKS2-C246-4 | |
9h | 220-250V | Blue | 3P+E | UKS2-C246-9 | |
6h | 380-415V | Red | 3P+E | UKS2-C246-6 | |
4h | 110-130V | Yellow | 3P+N+E | UKS2-C256-4 | |
9h | 220-250V | Blue | 3P+N+E | UKS2-C256-9 | |
6h | 380-415V | Red | 3P+N+E | UKS2-C256-6 |
1. High security and reliability
a. Different types of plugs and sockets prevent mis-insertion due to different plug clock positions, diameters and pole numbers, which is safe and reliable.
b. The ground pole socket in the socket is longer than the phase pole socket, which ensures that the ground pole is first connected when plugging, and the ground pole is finally separated when it is pulled out, which is very safe.
c. The elastic sleeve is added to the insert sleeve to ensure good contact with the plug after the connection, so as to avoid burning the plug socket due to poor contact heat; high protection level. Can be used under poor environmental conditions.
d. The anti-drop device is installed to greatly improve the safety and reliability of the plug and socket power connection.
2. It is made of high quality engineering plastic nylon (PA66).
High temperature resistance, good insulation performance; resistant to impact, not afraid of falling and stepping on, overcoming the shortcomings of the old plug and socket falling and fragile.
3. Easy to use
The new generation of industrial plugs and sockets are widely used because of their versatility, high safety and reliability, quick installation, convenient connection and insertion, simple operation, and wide variety of specifications, suitable for user selection and international integration.
Q: Are you factory?
A: Yes ,our factory is located in Wenzhou, one hour to Yiwu and two hours to Hangzhou by train, and one hour to Shanghai by air .Also very near to Wenzhou international Airport and Yueqing train station.
Q: Do you offer OEM service?
A: Yes,we have been providing OEM/ODM service to global manufacturers and suppliers for many years.
Q: What is your terms of payment?
A: T/T 30% as deposit,and 70% before delivery.We'll show you the photos of the products and packages before you pay the balance.
Q: What is your terms of delivery?
A: EXW, FOB, CIF.
Q: How about your delivery time?
A: Generally,it will take 3 weeks after receiving your advance payment.The specific delivery time depends on the items and the quantity of your order.
Zhejiang kripal Electric Co., Ltd. is a national high-tech enterprise specializing in R & D, production and sales. Our products mainly include: small, molded case circuit breakers, AC contactors, building electrical, outdoor waterproof, control components, industrial plugs and sockets, etc.
The company was founded in 1992, after 30 years of vigorous development, the existing plant area of more than 15000 square meters, more than 500 employees, including over 10 senior engineers, 30 professional technicists and 30 senior executives. The products have passed the certificate of UL,VDE,TUV, Kema,Semko,SAA,CE and CB test report,also ROHS international certification, and obtained the national 3C, ISO9001 quality certification.
The company adheres to the enterprise policy of "management, independent innovation, coordination and cooperation, brand supremacy" and abides by the promise of "virtue in the world". Practice the core values of "win-win cooperation with customers, common prosperity with employees, benefit creation for the company and harmonious contribution to society", and strive for the mission of "strive to realize the dream of professional electrical world brand".
We sincerely welcome new and old customers at home and abroad to contact us and create a better future.
