| Place of Origin: | CHINA |
| Brand Name: | KRIPAL |
| Certification: | CE |
| Model Number: | UKS -D336-6 |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | negotiable |
| Packaging Details: | each unit packed in a individual box |
| Delivery Time: | 20 days and depends on ordering quantity |
| Payment Terms: | T/T,L/C, D/P |
| Supply Ability: | 50000 pcs per month |
| Type: | Electrical Plug | Rated Current: | 63A,125A |
|---|---|---|---|
| Rated Voltage: | 110V,220V,380V | IP Rating: | IP67 |
| Material: | Nylon,PA,PC,Copper | Frequency: | 50/60Hz |
| Advantage: | Waterproof,Dustproof,Damp-proof | ||
| High Light: | 63A 230V Wall Mounted Plug,Single Phase IP67 Wall Mounted Plug |
||
| Current | Position | Voltage | Color | Poles | Model |
| 63A | 4h | 110-130V | Yellow | 2P+E | UKS-D336-4 |
| 6h | 220-250V | Blue | 2P+E | UKS-D336-6 | |
| 9h | 380-415V | Red | 2P+E | UKS-D336-9 | |
| 4h | 110-130V | Yellow | 3P+E | UKS-D346-4 | |
| 9h | 220-250V | Blue | 3P+E | UKS-D346-9 | |
| 6h | 380-415V | Red | 3P+E | UKS-D346-6 | |
| 4h | 110-130V | Yellow | 3P+N+E | UKS-D356-4 | |
| 9h | 220-250V | Blue | 3P+N+E | UKS-D356-9 | |
| 6h | 380-415V | Red | 3P+N+E | UKS-D356-6 | |
| 125A | 4h | 110-130V | Yellow | 2P+E | UKS-D436-4 |
| 6h | 220-250V | Blue | 2P+E | UKS-D436-6 | |
| 9h | 380-415V | Red | 2P+E | UKS-D436-9 | |
| 4h | 110-130V | Yellow | 3P+E | UKS-D446-4 | |
| 9h | 220-250V | Blue | 3P+E | UKS-D446-9 | |
| 6h | 380-415V | Red | 3P+E | UKS-D446-6 | |
| 4h | 110-130V | Yellow | 3P+N+E | UKS-D456-4 | |
| 9h | 220-250V | Blue | 3P+N+E | UKS-D456-9 | |
| 6h | 380-415V | Red | 3P+N+E | UKS-D456-6 |
|
Product |
Industrial Plug |
|
Rated current |
63A,125A |
|
No. of poles |
2P+E,3P+E,3P+N+E |
|
Voltage |
110V;220V-250V; 380V-415V |
|
Protection degree |
IP67 |
|
Power type |
Single Phase, Three Phase |
|
Conductor cross-sectional area (mm2) |
1.5-4(16A), 2.5-10(32A) |
|
Material |
NYLON,PA,PC,Copper |
|
Color |
110V(yellow) 220V,230V(blue) |
1. Safe and Reliable
①The rated voltage is indicated by the color of the shell, which is clear at a glance
②The grounding contact diameter and pole number of the products of the same specification are different to prevent mis-insertion
③Protection against electric shock
④High protection level: IP44 and IP67
⑤ storage device is provided to prevent the plug off each other, so that the reliability of the plug and receptacle greatly improved.
2.Durable
①Good mechanical properties, the shell is made of high quality engineering plastics, its high strength and impact resistance of rubber and plastic are anti-aging, not only can be used in the indoor, can also be used in the outdoor, durable components.
②Heat-resisting and Resistance to heat, enclosure and internal insulating parts are heat resistant
③Resistance to pull and plug under longstanding usage.
3. Strong universality
General use over all of the world, its specifications and varieties, can meet a variety of occasions and uses.
