Weatherproof Rotary Isolator Switch Safety Main Switch Surface Installation

China Weatherproof Rotary Isolator Switch Safety Main Switch Surface Installation supplier
Weatherproof Rotary Isolator Switch Safety Main Switch Surface Installation supplier Weatherproof Rotary Isolator Switch Safety Main Switch Surface Installation supplier Weatherproof Rotary Isolator Switch Safety Main Switch Surface Installation supplier

Large Image :  Weatherproof Rotary Isolator Switch Safety Main Switch Surface Installation

Product Details:

Place of Origin: China
Brand Name: KRIPAL
Certification: Semko,CE
Model Number: UKP3

Payment & Shipping Terms:

Minimum Order Quantity: 20pcs one carton
Price: negotiable
Packaging Details: Each unit packed in a individual box, outter carton size :61.5*37.5*29.5cm 20pcs/ctn
Delivery Time: 20 days and depends on ordering quantity
Payment Terms: T/T, L/C
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Product: Rotary Isolator Switch Cable Access: M20/25 Knockouts
Protection Grade: IP65 Red/Yellow Rings: Lockable
Enclosure: Brand-new PC Earth Terminals: Included
POLE: 2,3,4,5Poles Current: 32,40.50,63A


4P 63A Surface installation Weatherproof Rotary Isolator Safety main switch and maintenance switch


KRIPAL HAS THE DESIGN PATENT FOR THIS SERIES SWITCHES.

   Switchgear housed in moulded enclosures provides the basis for most industrial applications, and the added benefits offered by the 'UKP' range provide the user with a wealth of opportunities when selecting the correct item for a specific application. Enclosure  IP65 sealing. Good sealing is a feature of the 'UKP' range as is the ability to add a selection of auxiliary blocks providing additional contacts and a choice of Neutral assemblies.



Description:

1. These rotary isolator switches are used to switch power to commercial / light industrial applications.

2. The red switch can be used as an emergency stop, and can be locked in the “OFF” position using
     the yellow surrounding ring and padlock.

3. Easy cable access via M20/25 knockouts

4. The screws are captive retained and would not drop off when the lid is turned over.

5. Earth terminal is included

6. Enclosure: brand-new PC, White

7. Standard: manufactured and tested as IEC 60947-3


Specifications:



No.

Tech Parameters

requirement

1.

Rated voltage

230-440V

2.

rated current

10A,16A,20A,25A,32A,40A,50A,63A,80A,100A

3.

frequency

AC50HZ

4.

No. of poles

2P,3P,4P,5P

5.

No. of layers

make as required with circuit diagram

6.

panel size

64*64mm

7.

color of handle

Black/red



Optional:

a. Netural contacts

b. 1NO+1NC module

c. Color of handle and surroundings


Advantages:

Small size, multi-function, compact structure, high quality material, good insulation, agile operation, reliability, safety, good appearance.


Applications:

UKP series Disconnect Switches offer ideal features for their use as: ON-OFF Switches, Emergency-Off Switches, Maintenance Switches, Safety Switches, Distribution Switches, and Motor switches



Workshops:

KRIPAL's main workshops: Mould-building workshop, production workshop, injection workshop, punching workshop, Instrument Workshop, Welding workshop, Assembling workshop, Warehouse and etc

Quality:

There are four main production workshops in KRIPAL, every workshop hs an inspector to control every step's production and do test, in order to provide our customer the best quality and service.
KRIPAL's workers are disciplined, enthusiastic, efficient, and able to complete work on time and in volume. Therefore, we can guarantee high quality and good service. Please feel free to purchase from our company.

Weatherproof Rotary Isolator Switch Safety Main Switch Surface Installation

 Weatherproof Rotary Isolator Switch Safety Main Switch Surface Installation
p.s.: UKP3-4P63A 's production.


General Information:

KRIPAL 's Certificate: CCC, CE, CB, UL, Semko, KEMA, TUV, SAA, ISO9001-2000 and etc

KRIPAL 's Main market: Europe, Australia, Middle East, Asia, Africa, South of America.

KRIPAL 's Marketing channels: Internet (Google, B2B, Homepage); Exhibition (Canton Fair twice per year; overseas exhibition twice per year at least); Standing Clients;

Our factory's main business: Mould design, mould building, mould maintenance, production of parts & components, parts & components assembling, packing, test for parts & finished products, publicity-enterprise planning


Departments:

KRIPAL's main department : Administrative Department, HR Department, Financial Department, Internal Trade Department, International Trade Department, Technical Department, Planning Department, Production Department, Purchasing Department, Quality Inspection Department
